* This product is written on it casting (Made in Poland) and we are the only distributor in the arabic republic of egypt.

Print this Page
Send Email
GMB multi jet - wet dial

  • Multi jet water meter, wet dial, direct reading.
  • Available for cold water (30°C), sizes from Ø 15 to 50 mm (½” – 2”).
  • Suitable for domestic and industrial applications.
  • Long life and high accuracy guaranteed.


Technical Data



Calibro
Size
DN
mm
in
15
(1/2'')
20
(3/4'')
25
(1'')
32
(1'' 1/4)
40
(1'' 1/2)
50
(2'')

Portata massima
Max flow rate
Qmax
m³/h
3
5
7
12
20
30

Portata nominale
Nominal flow rate
Qn
m³/h
1.5
2.5
3.5
6
10
15

Portata di transizione
Transitional flow rate
Qt ±2%
l/h
120
200
280
480
800
3000

Portata minima
Min flow rate
Qmin
±5%
l/h
30
50
70
120
200
450

Sensibilità
Sensibility
l/h
10
14
17
27
46
75

Lettura minima
Min reading
l
0.05
0.05
0.05
0.05
0.05
0.05

Lettura massima
Max reading
m³
100.000
100.000
100.000
100.000
1.000.000
1.0000

Pressione max di esercizio
Max working pressure
bar
16
16
16
16
16
16

Classe B-H
Class B-H

Acqua fredda 0° - 30° C
Cold water 0° - 30° C

Trascinamento meccanico
Mechanical transmission

Lettura diretta a rulli numeratori
Immediate reading by numerical rolls

Quadrante bagnato
Wet dial






Dimensions and weights




Calibro
Size
mm
in
13
1/2''
20
3/4''
25
1''
32
1'' 1/4
40
1' 1/2'
50*
2''

L
mm
145-165-190
190
260
260
300
300

I
mm
225-245-270
290
360
380
440
460

H
mm
109
111
117
117
153
172

B
mm
100
100
104
104
126
160

D
in
3/4''
1''
1'' 1/4
1'' 1/2
2''
2'' 1/2

Pesi
Weights
Kg
1.35
1.45
2.04
2.11
4.58
7.25

* I contatori Ø 50 possono essere forniti flangiati secondo UNI 2223 PN 16
* The ø 50 meters can be supplied flanged according to UNI 2223 PN 16.
